Polyester filter bag seal ring for 60 Series Redi installations. 4.375″ inner diameter, 6.5″ outer diameter, 0.25″ thick. Provides tight, leak-resistant bag seal.
The IAC 1330281 filter bag seal ring is designed to create a secure, leak-free seal between filter bags and tubesheets in 60 Series Redi baghouse systems. Made from durable polyester, this ring offers excellent resistance to wear, dust abrasion, and heat up to standard operating conditions.
It features a 4.375″ inner diameter, 6.5″ outer diameter, and 0.25″ thickness, allowing for a snug fit between the filter bag collar and tubesheet hole. This ring helps prevent dust bypass and maintains system efficiency over time.
Perfect for retrofit or replacement in compatible baghouse units where precise sealing is critical.
IAC Model Number: 1330281
Product Type: Filter Bag Seal Ring
Inner Diameter: 4.375 in (111 mm)
Outer Diameter: 6.5 in (165 mm)
Thickness: 0.25 in (6.35 mm)
Material: Polyester
System Compatibility: 60 Series Redi
Color: Natural / White (unless specified)
Temperature Rating: Up to 275°F (135°C)
Application: Bag-to-tubesheet seal for dust collectors
