Part No. 2080001
IAC Differential Pressure Gauge – Magnehelic Model 2015, 0–15″ w.g., 4″ dial, for filter condition and airflow monitoring.
The IAC Model 2015 Magnehelic® Differential Pressure Gauge provides accurate and reliable measurement of low air pressure differentials, with a range of 0 to 15 inches water column (w.g.). It is ideal for monitoring filter condition, airflow, and system performance in dust collectors, HVAC systems, and other air handling equipment.
Its 4-inch dial face offers clear, easy-to-read markings, while the rugged die-cast aluminum housing and acrylic lens ensure durability in industrial environments. Two 1/8″ NPT pressure ports allow for connection to the high and low pressure sides of the system, enabling quick, accurate readings.
Key Features:
Type: Differential Pressure Gauge
Pressure Range: 0–15 inches water column
Dial Size: 4″ diameter
Case Material: Die-cast aluminum with baked enamel finish
Lens Material: Clear acrylic
Accuracy: ±2% of full scale
Connections: 1/8″ NPT high and low pressure ports
Applications: Filter condition monitoring, airflow measurement, system performance verification
Mounting Options: Surface or flush mount
