Timer Board – Dwyer DCT1010, 10 Position, 85–270 VAC 50/60 Hz, -40°F to +140°F, 10–600 ms On, 1–255 s Off

The IAC 2090324 timer board is the Dwyer DCT1010 model, a 10-position control board designed for 85–270 VAC 50/60 Hz operation. It offers adjustable on-times from 10 milliseconds to 600 milliseconds and off-times from 1 to 255 seconds, enabling precise control of pulse-cleaning cycles in dust collector systems.

Engineered for durability, the DCT1010 operates in extreme temperatures ranging from -40°F to +140°F, making it suitable for harsh industrial environments. Its universal voltage capability and wide timing range make it a versatile solution for multi-valve dust collection systems.

Key Features:

• IAC Part No.: 2090324

• Manufacturer: Dwyer

• OEM Part No.: DCT1010

• 10-position timer board

• Voltage: 85–270 VAC, 50/60 Hz

• On-time range: 10–600 milliseconds adjustable

• Off-time range: 1–255 seconds adjustable

• Operating temperature range: -40°F to +140°F

• Designed for dust collector pulse-cleaning systems

Cross Reference Compatibility:

• OEM Reference: Dwyer DCT1010

• Fits systems requiring 10-position AC timer boards with wide temperature tolerance
