Part No. 2040133
Bulkhead fitting – 1 1/2″ x 8″ carbon steel body, Nitrile gaskets, Quik-Joint coupling, 9 1/2″ assembled length.
The 2040133 bulkhead fitting is a 1 1/2-inch heavy-duty connector designed for through-wall or panel mounting in dust collector and pneumatic systems. Featuring an 8-inch carbon steel body with Nitrile (Buna) gaskets rated up to 260°F, this fitting ensures a secure, leak-resistant seal in high-demand industrial environments.
This unit includes a Quik-Joint full coupling for fast connection, plain steel end nuts for structural durability, and zinc-plated retainer rings for added corrosion protection. With a 9 1/2-inch assembled length, it’s well-suited for pulse valve manifolds, baghouse inlet/outlet piping, and other air handling applications.
OEM Models: 7381350 / 30644955
Connection Size: 1 1/2″
Seal Material: Nitrile (Buna) – rated to 260°F (127°C)
Body Length: 8″
Assembled Length: 9 1/2″
Coupling Type: Quik-Joint full coupling
Material – Body & End Nuts: Plain carbon steel
Retainer Rings: Zinc plated
Applications: Dust collector pulse valve assemblies, pneumatic conveying, industrial air handling
