PB57542-UBL-PP3-SBPTFE50 Pleated Bag Filter – 5.75″ x 42″, SBPTFE Media, UBL, 50 Pleats

PB57542-UBL-PP3-SBPTFE50 Pleated Bag Filter – 5.75″ x 42″, Spunbond Polyester with PTFE Membrane, 50 Pleats, Urethane Bottom Latch, Polypropylene End Caps, Heavy-Duty Core

The PB57542-UBL-PP3-SBPTFE50 is a premium pleated bag filter designed for high-performance filtration in demanding applications where fine, sticky, or hazardous dust must be controlled. Featuring 50 pleats of PTFE-laminated spunbond polyester (SBPTFE) media, it offers enhanced surface loading, excellent dust release, and high filtration efficiency, ideal for powder coating, chemical processing, food and pharmaceutical facilities, or any application with submicron particles.

Its 5.75″ diameter and 42″ length support extended service intervals and higher dust-loading capacity. The UBL (Urethane Bottom Latch) mount ensures secure, tool-free installation, while PP3 polypropylene end caps deliver corrosion resistance. A H3 heavy-duty galvanized core provides structural integrity during high-pressure pulse cleaning.

Key Features:

• Size: 5.75″ Diameter x 42″ Length

• Media: SBPTFE – Spunbond Polyester with PTFE Membrane

• Pleat Count: 50

• Filter Area: ~28–30 sq. ft. (estimated)

• Mounting Style: UBL – Urethane Bottom Latch

• End Cap Construction: PP3 – Polypropylene

• Support Core: H3 – Heavy-duty galvanized cage

• Efficiency Rating: ~MERV 15+

• Washable: Yes (gentle rinse; avoid aggressive detergents)

• Max Operating Temp: 200°F (93°C)

• Applications: Fine powders, sticky dust, food-grade and pharmaceutical dust collection, hazardous particulates

Cross Reference Compatibility

Interchangeable with other 5.75″ x 42″ pleated bag filters using PTFE media, UBL mounting, and 50-pleat configurations.

Manufacturer Cross References:

• Environmental Filter: PBF57542-SBPTFE50

• Clarcor / BHA: PF5.75x42SBPTFE50-UBL

• Fleetlife®: FL-PB57542SBPTFE50

• Imperial Systems: IMS-PB57542SBPTFE50

• Donaldson® / Torit®: PTFE retrofit-friendly (verify latch geometry)

PTFE membrane is ideal for pulse-jet collectors with fine or moist dusts. Confirm cap material and grounding requirements for hazardous dust applications.
